Face Recognition Measurement Human Temperature Screening Scanner

Android or Linux / 50000 pcs Face / Multiple Card / Under-screen Swipe / HIK Camera

  • N8-HIK Featured Image
  • N8-HIK Featured Image
  • N8-HIK Featured Image
  • N8-HIK Featured Image
  • N8-HIK
  • N8-HIK
  • N8-HIK
  • N8-HIK

N8-HIK

◉Infrared imaging sensor

◉Large Angle anthermic prime lens

◉Live Detection

◉Multi-touch Support

◉Proximity To Wake Up

◉8-inch HIGH-DEFINITION LCD display with full viewing Angle


N8-HIK indoor face recognition terminal

3601
xr_hand1
X5

Facial recognition is gradually applied to access control and attendance, creating a favorable "contactless" experience. The N8-HIK face
recognition terminal relies on advanced deep learning technology and practical functions to bring better security and higher eficiency for
access control and attendance tracking.

Specification

N8Hikdraw
Item Parameter
Dimension 293.3*127.2*32
Weight 1.15KG
CPU RV1109 dual-core A7,1.5GHz RK3288  Cortex-A17,quad-core 1.6G
GPU/NPU NPU  1.2T (With RV109) GPU  Mali-T760MP4 (With RK3288)
Flash RAM 1GB (With RV109) RAM 2GB (With RK3288)
ROM 4GB(With RV109) ROM 16GB (With RK3288)
OS Linux 4.19(With RV109) Android8.1(With RK3288)
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
Communication 10/100Mbps Ethernet
LCD 8 inch IPS HD(800*1280);
brightness 500cd/㎡
RGB Light support
IR Light support
Speaker Inside speaker,Power 1W
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
RGB Camera 2 million pixel camera, capture frame rate 25-25
Pixel:2 million
resolution:1920*1080
Pixel size:2.8um*2.8um
F-number:2.0
Focal length:4.3mm
View angle:68°
Dynamic range:105dB
IR Camera 2M
Relay Support 1 channel (NO,NC,COM)
RJ45 Support
USB HOST USB2.0
485 Support
Wiegand input or output ,TYP input
GPIO Support 3 channel(door magnets, door opening buttons, fire alarms)
Adapter DC12V-2A
Power TYP:<10W
MAX:<15W
Operation
Temperature
10℃~+35℃
Operation
humility
10%-90% No condensation
Storage
Temperature
⁃10℃~+50℃
Storage
humility
20%-90% No condensation
ESD ±6kV touch、±8kV Air
Watch Dog Support
WIFI IEEE802.11 b/g/n/ac (2.4G+5G)
Temperture camera
Resolution
120*160
Temperture
Measuring range
30~45℃
Temperature measurement accuracy ±0.5
Temperture camera
View angle
37.2°*50°
