Biometric Machine NFC Face Reader Time Attendance System

Android / 50000 pcs Face / Multiple Card / 10.1 Inch Touch Screen

  • BD1102 Featured Image
  • BD1102 Featured Image
  • BD1102 Featured Image
  • BD1102
  • BD1102
  • BD1102

BD1102

◉ 10.1″ LCD suitble for laboratory/meeting/interview

◉ Android 8.1 , easily secondary development with SDK

◉ Excellent Facial recognition Terminal with Liveness detection

◉ Multiple identification modes: FaceFinger print Mifare card

◉ Various Interfaces: LAN/Wiegand/Relay and BT/WIFI/4G/485(Optional )

◉ DC 12V/2A,POE(optional)


BD1012 indoor face recognition terminal

3601
xr_hand1
X5

Adopting RK3288 chip, which is a 4-core HD chip, it can support 4K*2K video. Equipped with Android OS, it can make your app development faster and easier. It is equipped with RGB camera and IR camera for live detection to prevent photo and video attacks. It is also equipped with visible light fill light and near infrared fill light to improve the accuracy and speed of recognition, making your management system more secure and convenient.

Specification

1012draw
Item Parameter
Dimension 310×175×32(mm)
Weight About 1.2kg
CPU RK3288  Cortex-A17,quad-core 1.6G
GPU Mali-T760MP4
Flash RAM 2GB
ROM 16GB
OS android8.1
Communication 10/100/1000Mbps Ethernet
LCD 10.1 inch IPS HD(1280*800);brightness 400cd/㎡
Speaker inside speaker,1.5W,
camera RGB camera:
2M, capture frame rate 25-25
IR camara:
2M,capture frame rate 25-25
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
Relay Support 1 channel (NO,NC,COM)
RJ45 Support
USB HOST USB2.0
SD card Support SD card:32GB
Wiegand input or output ,TYP input
GPIO Support 2 channel(door magnets, door opening buttons)
Adapter DC12V-2A
Power TYP:<10W
MAX:<15W
Operation
Temperature
0℃-45℃
Operation
humility
10%-90% No condensation
Storage
Temperature
-10℃~+60℃
Storage
humility
20%-90% No condensation
ESD ±6kV touch、±8kV Air
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
ID reader
(optional)
Distance:0-5cm
frequency:125KHz
peed <0.1S
QR reader
(optional)
Image(Pixels): 640 pixels(H) * 480 pixels(V)
FPS: 1/60s
Roll/Pitch/Yaw: 360°,±55°,±55°
Decode capability: QR、Data matrix、PDF7、Chinese information code
Minimum Resolution: ≥7.5mil
POE
(optional)
Optional,IEEE802.3AT
WIFI+Blue tooth
(optional)
IEEE802.11 b/g/n (2.4G)+Bluetooth 4.0
4G
(optional)
antenna:insde antenna
4G Support
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
