10-inch Facial Recognition Multimodal With RFID Recognition

Android / 50000 pcs Face / Multiple Card / 10.1 Inch Touch Screen

  • BD1011-R Featured Image
  • BD1011-R Featured Image
  • BD1011-R Featured Image
  • BD1011-R
  • BD1011-R
  • BD1011-R

BD1011-R

◉ 10.1″ LCD suitble for laboratory/meeting/interview

◉ Android 8.1 , easily secondary development with SDK

◉ Multiple identification modes: Mifare card/QR (Optional )

◉ Various Interfaces: LAN/Wiegand/Relay and BT/WIFI/4G/485(Optional )

◉ DC 12V/2A,POE(optional)


  • :
  • BD1011 indoor face recognition terminal

    3601
    xr_hand1
    X5

    Specification

    10116Cdraw
    Item Parameter
    Dimension 310×175×32(mm)
    Weight 1.2kg
    CPU RK3288  Cortex-A17,quad-core 1.6G
    GPU Mali-T760MP4
    Flash RAM 2GB
    ROM 16GB
    OS android8.1
    Communication 10/100/1000Mbps Ethernet
    LCD 10.1 inch IPS HD(1280*800);brightness 400cd/㎡
    Speaker inside speaker,1.5W,
    camera 0.3M
    TP 5 points Capacitive touch panel,
    reponse time<48ms,
    surface hardness>6H,
    transmittance≥85%
    Relay Support 1 channel (NO,NC,COM)
    RJ45 Support
    USB HOST USB2.0
    SD card Support SD card:32GB
    Wiegand input or output ,TYP input
    GPIO Support 2 channel(door magnets, door opening buttons)
    Adapter DC12V-2A
    Power TYP:<10W
    MAX:<15W
    Operation
    Temperature
    0℃-45℃
    Operation
    humility
    10%-90% No condensation
    Storage
    Temperature
    -10℃~+60℃
    Storage
    humility
    20%-90% No condensation
    ESD ±6kV touch、±8kV Air
    IC reader 13.56MHz,support M1/CPU,speed <0.1s
    Distance :2.5-5cm
    ID reader
    (optional)
    Distance:0-5cm
    frequency:125KHz
    peed <0.1S
    QR reader
    (optional)
    Image(Pixels): 640 pixels(H) * 480 pixels(V)
    FPS: 1/60s
    Roll/Pitch/Yaw: 360°,±55°,±55°
    Decode capability: QR、Data matrix、PDF7、Chinese information code
    Minimum Resolution: ≥7.5mil
    POE
    (optional)
    Optional,IEEE802.3AT
    WIFI+Blue tooth
    (optional)
    IEEE802.11 b/g/n (2.4G)+Bluetooth 4.0
    4G
    (optional)
    antenna:insde antenna
    4G Support
