Large Screen Advertising & Promotion of Biometric Identification Machines

Android / 50000 pcs Face / Multiple Card / 21.5 inch Touch Screen

  • BP30 Featured Image
  • BP30

BP30

◉ 21.5″ LCD suitble for advertising/ laboratory/exhibition

◉ Android 8.1 , easily secondary development with SDK

◉ Excellent Facial recognition Terminal with Liveness detection

◉ Multiple identification modes: FaceQR code Mifare card

◉ Various Interfaces: LAN/Wiegand/Relay and BT/WIFI/4G/485(Optional )

◉ DC 12V/4A,220V/POE(optional)


BP30 indoor face recognition terminal

3601
xr_hand1
X5

Specification

BP30draw
Item Parameter
Dimension 517x401x30mm
Weight 8.8kg
CPU RK3288  Cortex-A17,quad-core 1.6G
GPU Mali-T760MP4
Flash RAM 2GB
ROM 16GB
android android8.1
WIFI IEEE802.11 b/g/n (2.4G)
Communication 10/100/1000Mbps  Ethernet
Blue tooth Blue tooth 4.0
Speaker inside speaker *2 ,1.5W
Power button Support
Anti disassembly Support
Light sensing Support
TP 10 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
Relay Support 2 channel ,(NO,NC,COM)
RJ45 Support
USB HOST USB2.0,2 ports
SD Support SD card:32GB
485 Support
Wiegand Wiegand input.output
GPIO Support2 channel(door magnets, door opening buttons)
Power TYP:<20W
MAX:<30W
Operation
Temperature
0℃-45℃
Operation
humility
10%-90%,No condensation
Storage
Temperature
-10℃~+60℃
Storage
humility
20%-90% No condensation
ESD ±6kV touch、±8kV Air
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
QR reader Image(Pixels): 640 pixels(H) * 480 pixels(V)
FPS: 1/60s
Roll/Pitch/Yaw: 360°,±55°,±55°
Decode capability: QR、Data matrix、PDF7、Chinese information code
Minimum Resolution: ≥7.5mil
RGB Camera Pixel:2M
resolution:1920*1080
Pixel size:3um*3um
Dynamic range:105DB
Focal length:2.88mm
F-number:2.45
View angle:95.8°
Photograph Camera Pixel:5M
resolution:2952*1944
Pixel size:1.4um*1.4um
Focal length:3.25mm
F-number:2.0
View angle:72°
LCD size:21.5 inch
resolution:1920*1080
View angle:± 89°
Display colors:16.7M
contrast ratio:1000:1
brightness:500cd/m2
operation temperture:0-45℃
Adapter DC12V-4A
