10-inch Facial Recognition Multimodal With RFID & Fingerprint

Android / 3000~30000 pcs Fingerprint / 50000 pcs Face / Multiple Card / 10.1 Inch Touch Screen

  • BD1011-RF Featured Image
  • BD1011-RF Featured Image
  • BD1011-RF Featured Image
  • BD1011-RF
  • BD1011-RF
  • BD1011-RF

BD1011-RF

◉ 10.1″ LCD suitble for laboratory/meeting/interview

◉ Android 8.1 , easily secondary development with SDK

◉ Multiple identification modes: Mifare card/Finger print

◉ Various Interfaces: LAN/Wiegand/Relay and BT/WIFI/4G/485(Optional )

◉ DC 12V/2A,POE(optional)


BD1011 indoor face recognition terminal

3601
xr_hand1
X5

By the RK3288 chip, which is a 4-core HD chip and can support 4K*2K video. Equipped with Android operating system, which can make your application development faster and easier. This machine is equipped with monocular face recognition, which is cheaper, compatible with more algorithms and more stable. At the same time to meet the customer's needs for identification, we are equipped with fingerprint and RFID identification. RFID can support Proximity, NFC, CPU, HID/iclass, DESfire, Magnetic, Mifare, etc.

Specification

10116C8Tdraw
Item Parameter
Dimension 310×175×32(mm)
Weight 1.2kg
CPU RK3288  Cortex-A17,quad-core 1.6G
GPU Mali-T760MP4
Flash RAM 2GB
ROM 16GB
OS android8.1
Communication 10/100/1000Mbps Ethernet
LCD 10.1 inch IPS HD(1280*800);brightness 400cd/㎡
Speaker inside speaker,1.5W,
camera 0.3M
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
Relay Support 1 channel (NO,NC,COM)
RJ45 Support
USB HOST USB2.0
SD card Support SD card:32GB
Wiegand input or output ,TYP input
GPIO Support 2 channel(door magnets, door opening buttons)
Adapter DC12V-2A
Power TYP:<10W
MAX:<15W
Operation
Temperature
0℃-45℃
Operation
humility
10%-90% No condensation
Storage
Temperature
-10℃~+60℃
Storage
humility
20%-90% No condensation
ESD ±6kV touch、±8kV Air
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
ID reader
(optional)
Distance:0-5cm
frequency:125KHz
peed <0.1S
QR reader
(optional)
Image(Pixels): 640 pixels(H) * 480 pixels(V)
FPS: 1/60s
Roll/Pitch/Yaw: 360°,±55°,±55°
Decode capability: QR、Data matrix、PDF7、Chinese information code
Minimum Resolution: ≥7.5mil
POE
(optional)
Optional,IEEE802.3AT
WIFI+Blue tooth
(optional)
IEEE802.11 b/g/n (2.4G)+Bluetooth 4.0
4G
(optional)
antenna:insde antenna
4G Support
Fingerprint finger library:3000/10000/30000
recorder type:photoelectric type
Fingerprint registration times:3 times
fingerprints allowed to register:10/person
FAR:<0.0001 %
FRR:<0.1 %
speed:<2S
