5-inch Live Scan Facial Attendance Device Biometric Access Control

Android / 50000 pcs Face / Multiple Card / Under-screen Swipe

  • G5-S Featured Image
  • G5-S Featured Image
  • G5-S Featured Image
  • G5-S Featured Image
  • G5-S
  • G5-S
  • G5-S
  • G5-S

G5-S

◉ 5″ High definition LCD

◉ Android 8.1 , easily secondary development with SDK

◉ In-screen Mifare Card

◉ Excellent Facial recognition with 8-core Processor

◉ Easily extend 3rd party Device with BT


G5S indoor face recognition terminal

3601
xr_hand1
X5

With Qualcomm's 8-core chip, you can achieve high speed computing in any scenario, making the device run smoothly. Also equipped with Android OS, it can make your application development faster and easier. In addition, we provide a full set of SDK software package and API interface documentation, so that your backend can quickly contact to the device and solve your connection troubles. For face recognition convenience, it is paired with an RGB camera and IR camera for live detection and protection against photo and video attacks.
This unit supports functions such as door opening button, video intercom, off-screen swipe and extension of other devices.

Specification

G5Ddraw
Item Parameter
Dimension 146X74X20mm
Weight 240g
CPU Qualcomm snapdragon 450 processor 8-core1.8G
GPU Adreno GPU 506
Flash RAM 2GB
ROM 16GB
OS Android 8.1
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
WIFI IEEE802.11 b/g/n (2.4G)
Communication 10/100Mbps Ethernet
Blue tooth Blue tooth 4.1
LCD 5 inch IPS HD(720*1280);
brightness 500cd/㎡
RGB Light support
IR Light support
Speaker Inside speaker,Power 1W
Anti disassembly Support
Light sensing Support
Human body induction Support
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
RGB Camera 2 million pixel camera, capture frame rate 25-25
Pixel:2 million
resolution:1920*1080
Pixel size:1.75um*1.75um
F-number:2.6
Focal length:1.5mm
View angle:117°
Dynamic range:66dB
IR Camera 2M,capture frame rate 25-25
Relay Support 1 channel (NO,NC,COM)
RJ45 Support
485 Support
Wiegand Wiegand output,Wiegand 26 34
GPIO Support 3 channel(door magnets, door opening buttons, fire alarms)
Adapter DC12V-2A
Power TYP:<10W
Max:<18W
Operation
Temperature
0℃~+45℃
Operation
humility
10%-90% No condensation
Storage
Temperature
-10℃~+60℃
Storage
humility
20%-93%  No condensation
ESD ±6kV touch、±8kV Air
