Linux OS Access Control With Face Recognition & Mask Detection

Linux / 50000 pcs Face / Multiple Card / Under-screen Swipe

  • G5-B Featured Image
  • G5-B Featured Image
  • G5-B Featured Image
  • G5-B Featured Image
  • G5-B
  • G5-B
  • G5-B
  • G5-B

G5-B

◉ 5″ High definition LCD

◉ Linux OS more stable running systems

◉ In-screen Mifare Card

◉ Excellent Facial recognition with 1,2Tops NPU

◉ Easily extend 3rd party Device with BT


G5 indoor face recognition terminal

3601
xr_hand1
X5

Specification

G5draw
Item Parameter
Dimension 146X74X20mm
Weight 240g
CPU RV1109 dual-core A7,1.5GHz
NPU 1.2T
Flash RAM 1GB
ROM 4GB
OS Linux
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
WIFI IEEE802.11 b/g/n (2.4G)
Communication 10/100Mbps Ethernet
Blue tooth Blue tooth 4.1
LCD 5 inch IPS HD(720*1280);
brightness 500cd/㎡
RGB Light support
IR Light support
Speaker Inside speaker,Power 1W
Anti disassembly Support
Light sensing NA
Human body induction NA
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
RGB Camera 2 million pixel camera, capture frame rate 25-25
Pixel:2 million
resolution:1920*1080
Pixel size:1.75um*1.75um
F-number:2.6
Focal length:1.5mm
View angle:117°
Dynamic range:66dB
IR Camera 2M,capture frame rate 25-25
Relay Support 1 channel (NO,NC,COM)
RJ45 Support
485 Support
Wiegand Wiegand output,Wiegand 26 34
GPIO Support 3 channel(door magnets, door opening buttons, fire alarms)
Adapter DC12V-2A
Power TYP:<10W
Max:<18W
Operation
Temperature
0℃~+45℃
Operation
humility
10%-90% No condensation
Storage
Temperature
-10℃~+60℃
Storage
humility
20%-93%  No condensation
ESD ±6kV touch、±8kV Air
