Automatic Temperature Measurement Equipment With Extremely Small Errors

Android or Linux / 50000 pcs Face / Multiple Card / Under-screen Swipe / Black Body

  • N8-BB Featured Image
  • N8-BB

N8-BB

  • Super kernel: Adopt Hisilicon dual-core processor the system is high-speed and stable.
  •  Global top algorithm:  Adopt Megvii Face Algorithm with WDR Identification Technology.
  •  Liveness detection: effectively prevent the use of photos or videos as a substitute for recognition.
  •  Microwave sensor: accurate detection 2.5 meters can wake up recognition complete identification preparation.
  •  8 Inches touch screen: check device information operation setting  password to open door.

N8-BB indoor face recognition terminal

3601
xr_hand1
X5

Specification

N8BB
Item Parameter
Dimension 293.3*127.2*32
Weight 1.15KG
CPU RV1109 dual-core A7,1.5GHz RK3288  Cortex-A17,quad-core 1.6G
GPU/NPU NPU  1.2T (With RV109) GPU  Mali-T760MP4 (With RK3288)
Flash RAM 1GB (With RV109) RAM 2GB (With RK3288)
ROM 4GB(With RV109) ROM 16GB (With RK3288)
OS Linux 4.19(With RV109) Android8.1(With RK3288)
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
Communication 10/100Mbps Ethernet
LCD 8 inch IPS HD(800*1280);
brightness 500cd/㎡
RGB Light support
IR Light support
Speaker Inside speaker,Power 1W
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
RGB Camera 2 million pixel camera, capture frame rate 25-25
Pixel:2 million
resolution:1920*1080
Pixel size:2.8um*2.8um
F-number:2.0
Focal length:4.3mm
View angle:68°
Dynamic range:105dB
IR Camera 2M
Relay Support 1 channel (NO,NC,COM)
RJ45 Support
USB HOST USB2.0
485 Support
Wiegand input or output ,TYP input
GPIO Support 3 channel(door magnets, door opening buttons, fire alarms)
Adapter DC12V-2A
Power TYP:<10W
MAX:<15W
Operation
Temperature
10℃~+35℃
Operation
humility
10%-90% No condensation
Storage
Temperature
⁃10℃~+50℃
Storage
humility
20%-90% No condensation
ESD ±6kV touch、±8kV Air
Watch Dog Support
WIFI IEEE802.11 b/g/n/ac (2.4G+5G)
Temperture camera
Resolution
120*160
Temperture
Measuring range
30~45℃
Temperature measurement accuracy ±0.5
Temperture camera
View angle
37.2°*50°
