| Main functions | Consumer scenes, face recognition, live detection, swipe cards, sweep codes | ||
| Product size | Approx. 241*208*139 (mm) (final product dimensions are subject to actual product size) | ||
| Product weight | Approx. 1.16kG | ||
| Core Architecture | CPU | Qualcomm 450 8-core 1.8G | |
| GPU | Adreno GPU 506 | ||
| Memory | RAM 2GB | ||
| ROM 16GB | |||
| Operating systems | Android | android8.1 | |
| Face Recognition | Absence of algorithms | 1:N speed: ≤1S | |
| 1:1 speed: ≤1S | |||
| Maximum number of people supported: 100,000 | |||
| Recognition distance; 50cm-100cm | |||
| Recognition angle: upward tilt 35 degrees, downward tilt 35 degrees, left tilt 30 degrees, right tilt 30 degrees, plane rotation 35 degrees | |||
| Live detection: support live detection, live detection rate ≥99% | |||
| Recognition accuracy rate: ≥99% | |||
| False recognition rate: 0.5% | |||
| Communication | Ethernet | 10/100Mbps Ethernet | |
| WIFI | 2.4G/5G dual-band WIFI + Bluetooth | ||
| 4G | all-net, cat1 | ||
| Output | Display (identification side) | 7″ screen (resolution 1024*600); brightness 300cd/㎡; touchable | |
| Display (operator side) | 8″ screen (resolution 1280*800); brightness 300cd/㎡; touchable | ||
| White fill light | Support | ||
| Infrared fill light | Support | ||
| Status indicator | Red and green tips | ||
| Electroacoustic | Built-in speaker, 5W power | ||
| Audio playback support | |||
| Input | Switching keys | Hard on/off button | |
| Touch Screen | Dual-sided touch screen | ||
| 5-point capacitive touch screen. | |||
| Response time <48ms. | |||
| Surface hardness > 6H. | |||
| Light transmission rate ≥85% | |||
| IC card reader | Frequency 13.56MHz, M1/CPU support, 0.1s card reading | ||
| Card reading distance: 2.5-5cm | |||
| RGB camera | 2 million HD camera, dynamic 20-25 fps | ||
| Pixels: 2 million | |||
| Resolution: 1920*1080 | |||
| Pixel size: 2.9um*2.9um | |||
| Aperture: 2.0 | |||
| Focal length: 4.2mm | |||
| Field of view: 87° vertically, 57° horizontally | |||
| HDR: Support, 105dB | |||
| IR camera | 2 million HD camera, dynamic 20-25 fps | ||
| QR code camera | Support | ||
| Interface | RJ45 interface | Support | |
| USB HOST interface | USB 2.0, 1 way | ||
| 485 interface | Support | ||
| Power connector | Support | ||
| Power supply | Adapters | DC12V-3A | |
| Power | Rated power: <15.6W | ||
| Peak power: <24W | |||
| Protection class | IP54 | ||
| Reliability | Operating temperature | 0°C~+45°C | |
| Working humidity | Humidity 10% – 90%, non-condensing | ||
| Storage temperature | ⁃10℃~+60℃ | ||
| Storage humidity | 20% – 90% non-condensable | ||
| Uninterrupted work | 7*24 hours | ||
| ESD | ±6kV contact discharge, ±8kV air discharge | ||
| EFT | Achieved Level 2 standard | ||
| Surge | Achieved Level 2 standard | ||
| Packaging | Single product boxes | Neutral packaging with Will Certificate of Conformity, manual, warranty card | |
| Surface graphics on the box | |||
| With adapter 12V-3A | |||
| ROM | ROM Updates | Support for updates | |
| Switcher Logo | Will Logo | ||
| Default language | Default Chinese | ||
| Automatic standby | Software support | ||
| Battery | Built-in charging | Support | |
| Battery | Charging time | Approx. 6.5 hours | |
| Standby time | Approx. 6 hours | ||
| Working hours | Approx. 5.5 hours | ||
