8-inch Touch Screen Fingerprint Scanner With RFID

Android / 3000~30000 pcs Fingerprint / 50000 pcs Face / Multiple Card

  • A8 Featured Image
  • A8

A8

◉ 8″ LCD with Touch

◉ Auto wake up within 2.5m

◉ Mifare Card & Fingerprint

◉ Multiple identification modes: FaceFinger print Mifare card

◉ Various Interfaces: LAN/Wiegand/Relay and BT/WIFI/4G(Optional )

◉ IP66 Waterproof And Dustproof


A8 indoor face recognition terminal

3601
xr_hand1
X5

Specification

A8draw
Item Parameter
Dimension 267.3×172.2×26(mm)
Weight 1.6 KG
CPU RK3288  Cortex-A17,quad-core 1.6G
GPU/NPU GPU  Mali-T760MP4
Flash RAM 2GB
ROM 16GB
OS Android8.1
Face recognition 1:N Speed:≤1S
1:1Speed:≤1S
Face library:50000
Distance:TYP 1M,Max 2M;
visual angle:vertical ±35°,transverse±30°,
Support Life detection
Communication 10/100Mbps Ethernet
LCD 8 inch IPS HD(800*1280);
brightness 500cd/㎡
RGB Light support
IR Light support
Speaker Inside speaker,Power 1W
TP 5 points Capacitive touch panel,
reponse time<48ms,
surface hardness>6H,
transmittance≥85%
IC reader 13.56MHz,support M1/CPU,speed <0.1s
Distance :2.5-5cm
RGB Camera 2 million pixel camera, capture frame rate 25-25
Pixel:2 million
resolution:1920*1080
Pixel size:2.8um*2.8um
F-number:2.0
Focal length:4.3mm
View angle:68°
Dynamic range:105dB
IR Camera 2M,capture frame rate 25-25
Relay Support 3 channel NO,NC,COM
RJ45 Support
USB HOST USB2.0
485 Support
Wiegand input or output ,TYP input
GPIO Support 3 channel(door magnets, door opening buttons, fire alarms)
Adapter DC12V-2A
Power TYP:<10W
MAX:<15W
Operation
Temperature
⁃20℃~+60℃ (With RV109)
0℃~+45℃ (With RK3288)
Operation
humility
10%-90% No condensation
Storage
Temperature
⁃30℃~+70℃ (With RV109)
⁃10℃~+50℃ (With RK3288)
Storage
humility
20%-90% No condensation
ESD ±6kV touch、±8kV Air
Watch Dog Support
WIFI IEEE 802.11 b/g/n/ac (2.4G+5G)
Fingerprint finger library:3000/10000/30000
recorder type:photoelectric type
Fingerprint registration times:3 times
fingerprints allowed to register:10/person
FAR:<0.0001 %
FRR:<0.1 %
speed:<2S
